7.4. Oper Param (Operator Parameters)
Parameters Related with Velocity
Parameter
Meaning
Setting range
G00 Speed
G00 speed, which can be set in this
parameter or in the program file
Related with machine tool
G00 speed ≤ the max. velocity of machine
tool)
Gxx Speed Gxx speed
Related with machine tool
Whether manual operations affected Yes: affected
Ratio ON Manu by feedrate override
No: Not affected
The max. velocity of machine tool is related with the setting of pulse equivalent. For the detailed
expression, see chapter 6.1.2.
The relation between real feedrate and feedrate override is:
Real feedrate= Feedrate × Feedrate override
The least unit of feedrate override is 0.1, i.e. the override will increase (decrease) 0.1 after each press
of
or
, and the feedrate override displayed on the screen will increase (decrease) 10.
The adjustment range of feedrate override is 0.0~1.2. When the feedrate is adjusted, the value of
feedrate will also change accordingly.
Manual high speed and manual low speed are set under main interface; G00 speed ≥ processing
speed, and manual high speed ≥ manual low speed > 0.06
Parameters Related with Processing
Parameter
Back REF First
Lifts on Pause
Cycle Process
Cycle Times
Cycle Interval
S_Off in Intev
G73_G83
Retract
Ratio ON Manu
Meaning
Setting range
Whether to back to mechanical Yes: must back
origin forcibly before machining
No: Not forced
Lifting amount on pause
0~10000
Cycle Process
Whether to enable cycle process
Yes: enabled
No: not enabled
Cycle processing times, valid when
“Cycle Process” is set as “Yes”
1~9999
Interval of cycle processing
0~3600000
Yes: valid
Whether spindle stops in the interval
No: invalid
Retracting or spacing amount of
G73_G83 command
0~1000000
Whether manual operations affected Yes: affected
by feedrate override
No: Not affected
