this function, user can select the module to be processed. After these values are set, press “Up” or

“Down” key to select “Execute Now”, and then press [OK] to start machining instantly.

Note:

The default line No. of “Start Line” is the breakpoint line No. under this interface.

7.3.4. Machining Info

After this item is selected and [OK] key is pressed, the system will analyze the file currently

loaded automatically, calculating the needed time for file processing and the processing range of each

axis. The interface of analytic result is as shown in Fig. 7-7.

Time: 0：1：42

X ： 108

205

Y ：

117

Z ：

7.3.5.

Fig. 7-7 Analytic result of processing information

Park MCS Site Setup

For the detailed information, refer to Park MCS Site in chapter 6.5 Spindle Debugging.

7.3.6. Select WCS

Press “Menu” key→ select 3. Operations→ select 6. select Select WCS, and then press [OK] key

to enter the interface shown in Fig. 7-8, displaying the six workpiece coordinate systems from G54 to

G59.

G54 WCS

G55 WCS

G56 WCS

Select by [OK] key

Fig. 7-8 WCS selection interface

After pressing “Up” or “Down” key to select the corresponding WCS, press [OK] key to confirm

the selection. After confirmation, the number before X/Y/Z axis may change, WCSs of G54~G59

corresponding to 1~6 accordingly.
