ON/OFF Delay
Since it takes some time for spindle to reach the rated rotary speed or completely stop, tool
damage or scrap will occur if machining starts before spindle reaching the rated rotary speed or other
actions are performed before spindle stopping completely. This parameter helps user make spindle
reach the specified rotate speed when start-up or stop completely in the end
Initial Gear
It sets the default gear when spindle starts, and its value should be smaller than the total gear
number of spindle. Otherwise, the input value is invalid. If the input value of “Spindle Gears” is smaller
than that of “Initial Gear”, the setup is not effective, either.
Modification to this parameter becomes effective after reboot.
Max. Spdl Speed
It refers to the maximum allowable rotate speed of spindle; its value is consistent with the setting
of transducer.
Modification to this parameter becomes effective after reboot.
6.5.2. Park MCS Site
Press “Menu” key→ select 3. Operations→ select 5. Park MCS Site, and then press [OK] key to
enter the interface of “Park Mode” and “Park Site”, as shown in Fig. 6-7. The position of spindle can
be set here after machining ends.
1. Park Mode
2. Park Site
Fig. 6-7 Park MCS site interface
Select “Park Mode”, and then press [OK] key to enter the interface shown in Fig. 6-8.
Not move
To park site
To WCS Origin
[OK] Select
Fig. 6-8 Park mode selection
Press “Up” or “Down” key to select the desired item, and then press [OK] key to accomplish the
selection and return to the previous menu. If “To park site” is selected and confirmed, input or select
26
