Fig. 6-5 Prompt dialog box of backing to mechanical origin
This method can only call all the axes to back to mechanical origin. If you want to execute
backing to mechanical origin of a single axis, you need to enter menu page.
Press “Menu” key→ select 3. Operations→ select 1. Back REF Point, and then press [OK] key to
enter setup interface of backing to mechanical origin, in which press “Up” or “Down” key to select the
desired mode. Then press [OK] key to execute backing to mechanical origin in the selected way. It is
recommended to execute “Z Home” firstly. If “X Home” or “Y Home” is executed firstly, a message
shown in Fig. 6-6 will be displayed prompting to execute “Z Home” firstly. To see all the information,
press “Up” and “Down” keys.
Dangerous
operation,
OK
ESC
Fig. 6-6 Dangerous prompt for operation of backing to mechanical origin
At this time, you can press [OK] key to enter the processing page and execute backing to
mechanical origin for the selected axis, or press [ESC] to cancel and return to the previous interface.
6.5. Spindle Debugging
This system provides the control functions to control spindle motor through parameters of
“Spindle Gears”, “ON/OFF Delay”, “Initial Gear” and “Max. Spdl Speed”. Spindle speed can be revised
during processing under the condition that the interface board and frequency converter have been
well connected.
6.5.1. Spindle Setup
Press “Menu” key→ select 5. Mfr Param→ select 6. Spindle Set, and then press [OK] key to enter
spindle setup interface, in which press “Up” or “Down” key to select the corresponding parameter for
modification.
Spindle Gears
Currently, the maximum 8-gear is supported.
Specialized, Concentrated, Focused
25
