System
port No.
0
1
2
3
4
5
6
7
GX07(ZORG)
GX08(ZLM+)
GX09(ZLM-)
GX10
GX11
GX12
GX13
GX14
GX15
GX16
Mechanical origin signal of
Z axis
Positive limit signal of Z
axis
Negative limit signal of Z
axis
Extended input 0
Extended input 1
Extended input 2
Extended input 3
Extended input 4
E-stop alarm signal input
Tool presetting signal input
External connection with mechanical,
photoelectrical and proximity switch
External connection with mechanical,
photoelectrical and proximity switch
External connection with mechanical,
photoelectrical and proximity switch
External connection with E-stop button on
the machine tool
Table 6 Corresponding signal of system output ports
Terminal
name
Corresponding signal
Remark
GY013(SP-) Control port of spindle
reverse rotation
GY014(SP+)
Control port of spindle
forward rotation
Control ports of multi-section spindle
GY15(S_2)
Output port of spindle gears with at most 8 gears of speed
speed gear 2
control; COM of spindle connected with
GND of terminal during wiring
GY16(S_1)
Output port of spindle
speed gear 1
GY17(S_0)
Output port of spindle
speed gear 0
GY18
Output port of workpiece
cooling
GY19
Output port of spindle
coolant
GY20
Output port of auto
lubricating fluid
