the main page, and then manually move the machine tool to release limit.
X soft limit
OK
ESC
Fig. 6-3 Software limit prompt
Modification to this parameter becomes valid after system reboot.
6.3. Port Polarity
The polarities of input/ output ports in software are specified in terms of the switch type: the
polarity of normally closed switch is “P”; the polarity of normally open switch is “N”. The corresponding
relation between system port No. and ports on the terminal board is as shown in Table 5 and Table 6.
The method to modify port polarity is as following: press “Menu” key→ select 8. Diagnosis→
select 2. Port List, and then press [OK] key to enter the interface shown in Fig. 6-4. At this time, you
can press “Up” or “Down” key to move to the port, and then press “Shift” key to change its polarity.
After its polarity change, press [OK] to save the modification.
IN GX01 · P
IN GX02 ○ N
IN GX03 ○ N
IN GX04 ○ N
System
port No.
0
1
2
3
4
5
Fig. 6-4 Modification interface of port polarity
Table 5 Corresponding signal of system input ports
Terminal
name
Corresponding signal
Remark
GX01(XORG)
Mechanical origin signal of External connection with mechanical,
X axis
photoelectrical and proximity switch
GX02(XLM+)
Positive limit signal of X External connection with mechanical,
axis
photoelectrical and proximity switch
GX03(XLM-)
Negative limit signal of X External connection with mechanical,
axis
photoelectrical and proximity switch
GX04(YORG)
Mechanical origin signal of External connection with mechanical,
Y axis
photoelectrical and proximity switch
GX05(YLM+) Positive limit signal of Y External connection with mechanical,
axis
photoelectrical and proximity switch
GX06(YLM-) Negative limit signal of Y External connection with mechanical,
axis
photoelectrical and proximity switch
22
