5.4. Modification Method of System Parameters

Modification of system parameters can be divided into two types.

Input of Numerical Value

After entering parameter modification page, directly input the desired digit, and then press [OK] to

save it or press [ESC] to return to the previous menu. Only when [OK] is pressed can the modification

be saved after parameter modification each time.

For example: modification method for the parameter “REFP Speed” is as follows.

Speed (mm/min)

X Axis:

Y Axis:

Z Axis:

1800.000

1500.000

Fig. 5-2 Modification interface of “REFP Speed”

Press “Menu” key→ select 5. Mfr Param→ select 5. REF. Point Set→ select 1. REFP Speed, and

then press [OK] key to enter the interface shown in Fig. 5-2, and then press “Up” and “Down” key to

select the axis speed parameter to be modified. When the cursor is on the item currently selected,

enter the new parameter value directly and then press [OK] to save it.

Note:

If you switch to another parameter without saving the input value during parameter modification, this new value

will not be saved and the original value will be restored.

Parameter Item Selection

Select a parameter item by directly pressing “UP” or “Down” key.

For example: modification method for the parameter “REFP Dir” is as follows.

Homing Direction

X Axis:

Y Axis:

Z Axis:

Negative

Positive

Fig. 5-3 Modification interface of “REFP Dir”

Press “Menu” key→ select 5. Mfr Param→ select 5. REF. Point Set→ select 2. REFP Dir, and

then press [OK] key to enter the interface shown in Fig. 5-3, and then press “Up” and “Down” key to

select the axis direction parameter to be modified. When the cursor is on the item currently selected,

press [OK] key to enter the interface shown in Fig. 5-4, arrow indicating the currently selected item.

Then press [Up] or [Down] key to select the desired item, and then press [OK] key to confirm the
