O1801
N1 G20
N2 G17 G40 G80
N3 G90 G54 G00 X5.5 Y3.1 S1000 M03
(Use G54)
N4 G43 Z0.1 H01 M08
N5 G99 G82 R0.1 Z-0.14 P100 F8.0
N6 G55 X5.5 Y3.1
(Switch to G55)
N7 G56 X5.5 Y3.1
(Switch to G56)
N8 G80 Z1.0 M09
N9 G91 G54 G28 Z0 M05
(Switch to G54)
N10 M01
…
Program segment N3~N5 is related to the first workpiece, within the G54 workpiece coordinate
system; program segment N6 drills the hole in the second workpiece of the same batch within the
G55 workpiece coordinate system; program segment N7 drills the third hole in the third workpiece of
the same batch within the G56 workpiece coordinate system.
Aiming at all the coordinate systems, public offset is used to adjust the workpiece origin of X, Y
and Z axes, without changing the offset value of G54~G59.
Workpiece offset, tool offset and public offset meet the following expression:
Workpiece coordinate = Mechanical coordinate – Workpiece offset – Tool offset – Public offset
