4.1. Operation Mode and State
4.1.1. Operation Mode
Regarding users’ operation to the machine tool, there are several operation modes as below. And
it’s very important to comprehend them for correct operation.
Auto Mode
Under automatic operation mode, the machine tool generates motions through the procedure
loaded in advance. Therefore, the processing procedure must have been loaded.
Manual Mode
To meet the requirements of manual motion under different situations, the system provides “Jog”
and “Step” motion modes.
¾ Jog motion mode: there is no concrete data control under this mode, fit for tuning the mechanical
coordinates roughly.
¾ Step motion mode: this motion mode is applicable to tuning the mechanical coordinates
accurately.
4.1.2. Operation State
In terms of the motion mode of the machine tool, each operation mode can be divided into the
following types of operation states; it is operation mode and operation state that decide the state of
the machine tool.
IDLE State
Idle state is the most common state. Under this state, the machine has no motion to output, but is
ready to accept any new task.
ESTOP State
This is an abnormal state. When there is an error in the hardware of machine tool, the system will
enter into this state and implement the predetermined protection actions, such as closing spindle
motor and cooling pump. Under this state, the machine tool is locked and can not carry out any new
action.
Running State
When the machine tool is implementing any action, the system enters into Running State.
Pause State
