does not need update, system application can be updated directly following the below steps:
1. Insert the USB flash disk, with the system application to be updated under its root menu, into the
USB interface of NK105 control box.
2. Power on NK105, then press
to enter menu page after entering system interface, .and
then select “7. System Upkeep” and “3. System Update” in turn, and then operate according to
the prompt on the screen until “USB Available Now” appears. And then press “OK” key to enter
update system interface in which select “Delete parameters”. After configuration files are deleted,
select “Update system” to start updating the system application. After update completes, the
system will be rebooted automatically.
Notice:
Ex-factory parameters need restoring after each system update. If “Delete parameters” is not selected in the
process of update, it is a must to restore ex-factory parameters after updating system, following the below
method: after the system is rebooted, press
to enter menu page; and then select “6. Param Upkeep” and
“3. Factory Params” sequentially, and then operate according to the prompt on the screen.
