3. System Installation
3.1. Basic Configuration of Ncstudio
Basic Configuration of NK105 System
Memory:
Flash:
Monitor:
128M
256M
128 × 64 graphic LCD module
3.2. Ncstudio System Update
User can directly use the NK105 he got since the system has been installed. If breakdown occurs,
user can update the system.
3.2.1. Configuration Update
Prepare an USB flash disk (above 1G) with the system image and application to be updated.
3.2.2. System Mirror Update
1. Insert the USB flash disk, with the system mirror “EBOOT105.nb0”, “NK105.nb0” and system
application to be updated under its root menu, into the USB interface of NK105 control box.
2. Power on NK105, and then press the “Menu” key
to enter update selection interface
automatically. Press “3” to select “OS” to start updating system image. Note that this process is a
little long, about 3 minutes. After write-in finishes, “USB Available Now!” will be displayed on the
screen. And then press “OK” key to enter update system interface in which select “Delete
parameters”. After configuration files are deleted, select “Update system” to start updating the
system application. After update completes, the system will be rebooted automatically.
Notice:
Ex-factory parameters need restoring after each system update. If “Delete parameters” is not selected in the
process of update, it is a must to restore ex-factory parameters after updating system, following the below
method: after the system is rebooted, press
to enter menu page; and then select “6. Param Upkeep”, “3.
Factory Params” sequentially, and then operate according to the prompt on the screen.
3.2.3. System Application Update
System application update is included in the process of system image update. If system image
