Terminal name
GND
+24V IN
GX01(XORG)
GX02(XLM+)
GX03(XLM-)
GX04(YORG)
GX05(YLM+)
GX06(YLM-)
GX07(ZORG)
GX08(ZLM+)
GX09(ZLM-)
GX10
GX11
GX12
GX13
GX14
GX15
GX16
Table 2 Input port signal explanation
Corresponding signal
Remark
Power GND or COM port
+24V DC power input
The two GND on power terminal are
connected with power GND and earth
respectively while GND on other terminals
can be used as COM signal.
External connection with +24V DC power
Mechanical origin signal of
X-axis
Positive limit signal of
X-axis
Negative limit signal of
X-axis
Mechanical origin signal of
Y-axis
Positive limit signal of
Y-axis
Negative limit signal of
Y-axis
Mechanical origin signal of
Z-axis
External connection with mechanical,
photoelectric and proximity switch
External connection with mechanical,
photoelectric and proximity switch
External connection with mechanical,
photoelectric and proximity switch
External connection with mechanical,
photoelectric and proximity switch
External connection with mechanical,
photoelectric and proximity switch
External connection with mechanical,
photoelectric and proximity switch
External connection with mechanical,
photoelectric and proximity switch
Positive limit signal of
Z-axis
External connection with mechanical,
photoelectric and proximity switch
Negative limit signal of
Z-axis
External connection with mechanical,
photoelectric and proximity switch
Extended input 0
Extended input 1
Extended input 2
Extended input 3
Extended input 4
External connection with E-stop button of
E-stop alarm signal input
machine tool
Tool calibration input
2.2. Input Interface of +24V Power
Input interface of +24V power is for external connection with 24V power. And its pin definition is
as shown in Fig. 2-2, in which
earth.
is connected to grounding copper plate of machine tool, namely to
