Terminal name
GY01(XD-)
GY02(XD+)
GY03(XP-)
GY04(XP+)
GY05(YD-)
GY06(YD+)
GY07(YP-)
GY08(YP+)
GY09(ZD-)
GY010(ZD+)
GY011(ZP-)
GY012(ZP+)
GY013(SP-)
GY014(SP+)
GY15(S_2)
GY16(S_1)
GY17(S_0)
GY18
GY19
GY20
+24V OUT
Table 1 Output port signal explanation
Corresponding signal
Remark
Negative differential signal
along X-axis
Positive differential signal
along X-axis
Pulse negative differential
signal of X-axis
Pulse positive differential
signal of X-axis
Negative differential signal
along Y-axis
Positive differential signal
along Y-axis
Pulse negative differential
signal of Y-axis
Pulse positive differential
signal of Y-axis
Negative differential signal
along Z-axis
Positive differential signal
along Z-axis
Pulse negative differential
signal of Z-axis
Pulse positive differential
signal of Z-axis
Spindle reverse rotation
control port
Spindle forward rotation
control port
2nd gear output port of
spindle speed
1st gear output port of
spindle speed
0th gear output port of
spindle speed
Workpiece cooling output
port
Spindle coolant output port
Auto lubricant output port
+24V output
XD+ and XD- are differential pair signals
along X axis.
XP+ and XP- are differential pair signals of
X-axis pulse.
YD+ and YD- are differential pair signals
along Y-axis.
YP+ and YP- are pulse differential pair signals
of Y-axis.
ZD+ and ZD- are differential pair signals along
Z-axis.
ZP+ and ZP- are pulse differential pair signals
of Z-axis.
Multi-step spindle gear control ports: they can
provide at most 8-gear speed control; in
wiring, COM of spindle needs joining to GND
of terminal.
It is connected with +24V power, available of
use.
