1.1 Briefing
RDC6445G/S Control System manual
RDC6445G/S system is a new generation system for control of laser engraving and cutting,
which is developed by RD Co., Ltd. In addition to high hardware stability, high voltage or static
electricity rejection, and friendly 5’’ TFT man-machine display. This system is provided with
stronger software function including perfect 4-axle motion control function, large-capacity file
storage, two-channel adjustable digits laser power control interface, USB driver of stronger
compatibility, multi-channel general/special IO control, and, this system can communicate with
PC by USB2.0 or Ethernet, and the communication mode is automatically checked by the system.
The basic functions of RDC6445G and RDC6445S are the same from the perspective of users.
Only RDC6445S has on-board clock logic and uses the term encryption logic in the form of
authorization code.
1.2 Description of Controller Model
1.3 Comparison of Controller Performance
Power
Feature
Laser Port
Feature
RDLC
420
One-way 5V,
one-way
24V,
independen
t
One-way
digit and
one-way
analog
RDC6332G
Only one-way
24V (compatible
with 36V for
power supply,
but
not
recommended)
Two-way digits
and two-way
analog port,
settable
independently
and
RDC6342G
Only one-way
24V (compatible
with 36V for
power supply,
but
not
recommended)
Two-way digits
and two-way
analog
port,
settable
independently
and
RDC644XG
Only one-way 24V
(compatible with
36V for power
supply, but not
recommended)
Two-way digits port,
settable
independently and
non-interacted
