Laser Engraving & Cutting Control System Manual

5.4 Quick Operation

5.4.1 Click Right Button of Mouse

Clicking the RIGHT button of the mouse will enable and pop-up a Quick Operation Box showing three (3) dialogs as

indicated below:

In the graph:

In the blank area when graph exists:

5.4.2 Ctrl+A

This is to SELECT ALL the graphs in the drawing area.

5.4.3 Ctrl+Y

This action will MOVE the selected graph to the center of the drawing area. Without selecting any graphics, the whole

graph will be moved to the center of the drawing area.

5.5 Description of Auto Separation 2-Head Machine

5.5.1 Working condition

The TWO laser heads are fixed on ONE belt.

62
