5 Appendixes

Laser Engraving & Cutting Control System Manual

5.1 IP Set

There are 2 IP modes: AUTO and STATIC (MANUAL). The default is ‘AUTO’.

When the mode is on ‘STATIC (MANUAL)’, you can input any number to identify different machines. When on ‘STATIC

(MANUAL)’ mode, the computer will instantly communicate with the controller (in approximately 1 second). When on

‘AUTO’ mode, it will take about 10 seconds to communicate with the controller. If a router is connected to the system, the

computer communicates with the controller in 1 second no irregardless of the mode.

5.2 Controlling Several Machines in One System

IMPORTANT: *One computer will control ONE machine at a time.*

5.2.1 General Info

Both NET and USB modes are all supported. TruCUT Laser Software will acquire the machine ID and load the CFG

(configuration) file automatically when the computer communicates with ONE machine at a time.

5.2.2 Setting machine ID

Setting the machine’s ID is done in the supporting interface of the PAD panel. The TruCUT Laser Software will not allow

the machine’s ID to be duplicated.

5.2.3 Machine setting

When TruCUT Laser Software acquires the machine’s ID, a CFG file will be generated accordingly. Input your intended

parameters and SAVE. Then download to the controller.
