Install CorelDRAW Graphics Suite



This section contains the following topics:

•	System requirements

•	Prepare for installation

•	Install CorelDRAW Graphics Suite applications

•	Installation options

•	Modify and repair installations

•	Uninstall CorelDRAW Graphics Suite

•

FAQ

System requirements

The following list includes the minimum system requirements. Note that for optimum performance, you need more RAM and hard disk space than indicated in the list.

•	Windows 7, Windows 8, or Windows 10, in 32-bit or 64-bit, all with the latest updates and service packs

•	Intel Core i3/5/7 or AMD Athlon 64

•

2 GB RAM

•	1 GB hard disk space

Electronic software downloads require more space to allow for the download, the uncompressed setup files, and the actual installation, which includes copies of the source files as well.

•	Mouse, tablet, or multi-touch screen

•	Display resolution

•

1280 x 720 screen resolution at 100% (96 dpi)

•

1920 x 1080 at 150%

•

2560 x 1440 at 200%

•	DVD drive (required for installing the box version of the software)

•	Microsoft .NET Framework 4.7.2

•	Microsoft Internet Explorer 11 or later

•	Internet connection is required to sign in to authenticate CorelDRAW Graphics Suite, receive performance and stability updates, and use online features, such as QR Codes.

If the required version of Microsoft .NET Framework is not available on your computer, it will be installed during product installation.

Prepare for installation

•	Make sure that your system’s date and time are set correctly.

•	Make sure that your system has the latest updates installed.

•	Close all applications, including all virus detection programs and applications that are open in the system tray or on the Windows taskbar. Not doing so may increase the installation time and interfere with the installation.

•	Log in as a user with administrative privileges.

•	Make sure that you have enough free disk space available on the drive where you want to install the application.

•	Delete the contents of the system’s TEMP folders to avoid file and memory conflicts. To navigate to the Temp folders, type %temp% in the Search box on the Windows 7 SP1 or Windows 10 Start menu, or the Windows 8 desktop.

•	Make sure that your system is connected to the Internet.

•	Install CorelDRAW Graphics Suite in its own directory to avoid conflicts with previous versions.

Install CorelDRAW Graphics Suite applications

The installation wizard makes it easy to install CorelDRAW Graphics Suite applications and components. You can choose a typical installation to quickly install the suite, or you can customize the installation by choosing different options.

To install CorelDRAW Graphics Suite applications

1	Close all applications, including all virus detection programs.

For smooth installation, we recommend that you restart Windows. This action will ensure that no restart is required by the latest system updates, and there are no memory issues.

2	Do one of the following:

•

Download the product from the link provided on your order confirmation.

•

Insert the DVD in the DVD drive.

3	In the installation wizard, review the End User License Agreement and the Terms of Service by clicking the corresponding links.

4	Enable the I agree to the End User License Agreement check box, and click Accept.

5	Type your name in the Full name text box.

6	Type your serial number in the Serial number text box.

The serial number is not case-sensitive, and the dashes are optional.

7	Click Next.

8	Follow the instructions for installing the software.

Installation options

You can choose between the following types of installations:

•	Typical installation — automatically installs the main programs and utilities of the suite to a default location in the Program Files folder. If later you need a component that is not installed, you can modify your installation.

•	Custom installation — lets you choose additional features, exclude components that you don’t need, and specify where to install the suite.

•	Deployment — available only for multiseat purchases. This option lets you create a server image for installing the software to individual workstations. For more information, see the CorelDRAW Graphics Suite 2019 Deployment Guide.

Programs

The following table lists the programs that are installed by default. To exclude a program from the installation, you must choose Custom installation.



Program	Description
CorelDRAW	An intuitive and versatile graphics application for creating high-quality vector illustrations, logo designs, and page layouts
Corel PHOTO-PAINT	A complete image-editing application that lets you retouch and enhance photos as well as create original bitmap illustrations and paintings
Corel CAPTURE	An easy-to-use application for capturing images from your computer screen
Corel Font Manager	An application for finding, organizing, and managing fonts

Program features and utilities

The following table lists the program features that you can install. Not all components are available in all versions of the software.

Feature or utility	Description	Notes
Microsoft Visual Basic for Applications 7.1	A subset of the Microsoft Visual Basic (VB) programming environment, which is suitable for beginners.	You can use VBA to create basic macros for personal use, but you can also use it to create more advanced macro projects.
Microsoft Visual Studio Tools for Applications (VSTA)	A built-in program environment that allows developers and other programming experts to use VSTA for creating the most advanced macro projects	To use VSTA with CorelDRAW Graphics Suite, you must have your own copy of Microsoft Visual Studio 2017 installed. If you install Microsoft Visual Studio after installing CorelDRAW Graphics Suite, you must re-install the VSTA feature by modifying your CorelDRAW Graphics Suite installation. For more information, see To modify or repair a CorelDRAW Graphics Suite installation.
Windows Shell Extension	Lets you view thumbnails of native Corel files such as CorelDRAW (CDR), Corel PHOTO-PAINT (CPT), pattern fill (FILL), and other native file.	If you have installed CorelDRAW Graphics Suite or CorelDRAW Technical Suite before, this option does not appear in the installation wizard.
GPL Ghostscript	Highly recommended if you import EPS and PDF files in your documents. This feature lets you isolate and use individual elements of imported EPS files rather than only header images. It also improves the import of PDF files generated by third-party applications.	Included with the Typical installation
Language packs	Let you use the programs and Help in two or more languages	This option is included only with multilingual versions of the software and requires Custom installation.
Install desktop shortcuts	Adds product icons to your desktop for easy access	Included with the Typical installation
Copy installation files	Lets you maintain and update the software without using the installation disc	Included with the Typical installation

Modify and repair installations

You can also use the installation wizard to do the following:

•	modify the current installation by adding or deleting components

•	repair the current installation by fixing errors such as missing or corrupt files as well as inaccurate shortcuts and registry entries

Repairing an installation is helpful when you encounter problems in using the application, or when you suspect that the installation is corrupt.

Before repairing an installation, try resetting the current workspace to the default settings by holding down F8 while starting the application. Note that when you reset the workspace, all workspace preferences are reset.

To modify or repair a CorelDRAW Graphics Suite installation

1	Close all applications.

2	On the Windows Control Panel, click Uninstall a program.

3	Double-click the suite’s name on the Uninstall or change a program page.

4	Enable the Modify option or the Repair option in the wizard that appears, and follow the instructions.

Program features and utilities that are already installed may not appear in the wizard, or their check boxes appear disabled.

Certain features, such as Copy installation files and Install desktop shortcuts, cannot be added by modifying your installation.

Uninstall CorelDRAW Graphics Suite

You can uninstall CorelDRAW Graphics Suite from the Control Panel. If you want to uninstall the product and then reinstall it with the same serial number on another computer, make sure to uninstall while being connected to the Internet. This will restore by one the number of computers on which you can legitimately install the product.

To uninstall CorelDRAW Graphics Suite

1	On the Windows Control Panel, click Uninstall a program.

2	Double-click the suite’s name on the Uninstall or change a program page.

3	Enable the Remove option in the wizard that appears, and follow the instructions.

To completely uninstall the product by removing user files, such as presets, user-created fills, and customized files, enable the Remove user files check box.

Any additional components and applications that you installed with the suite, such as the Corel Graphics - Windows Shell Extension, GPL Ghostscript, or Microsoft Visual Studio Tools for Applications (VSTA), must be uninstalled separately.

FAQ

If your question is not included in the list of frequently asked questions (FAQ) below, visit Corel Support Services, and search the Corel Knowledge Base.

•	I am upgrading my version of the software. Do I need to uninstall the previous version?

•	What is the difference between an upgrade and an update?

•	What if I lost my serial number and need to reinstall the software?

•	What is the difference between Typical and Custom installation? Which type of installation is suitable for me?

•	Why do you ask me to update my operating system with the latest service packs and critical updates?

•	How do I deploy CorelDRAW Graphics Suite to my organization’s network?

•	How do I change the language of the user interface and Help?

I am upgrading my version of the software. Do I need to uninstall the previous version?

No, you don’t need to uninstall the previous version. By default, the new version is installed to a separate folder, which ensures that you can work with both versions. Do not change the installation folder to install the upgrade and the previous version to the same folder.

What is the difference between an upgrade and an update?

An upgrade lets you install the latest major version of the software. After a major version is released, updates usually follow to offer defect fixes, and performance and stability improvements. Updates have the name of the major version with a number appended — for example, .1. Usually, the application notifies you when a product update is available, but you can also check for updates by clicking Help Updates.

What if I lost my serial number and need to reinstall the software?

Do one of the following:

•

For download versions, check the email you received from Corel when you purchased the product.

•

Sign in on corel.com to access Your Account page.

•

If you purchased a box, check the cover of the installation disk.

What is the difference between Typical and Custom installation? Which type of installation is suitable for me?

See Installation options.

Why do you ask me to update my operating system with the latest service packs and critical updates?

We ask you to install the latest service packs and critical updates in order to:

•

protect your computer from malicious software

•

resolve Windows issues and defects

•

ensure smooth operation of the operating system and your Corel software

•

help meet the minimum system requirements

•

help speed up the installation process

•

reduce the likelihood of needing to restart your operating system

•

ensure that system drivers are up-to-date and optimized for the suite.

How do I deploy CorelDRAW Graphics Suite to my organization’s network?

If you purchased multiple licenses of CorelDRAW Graphics Suite, you have the option of deploying the applications to your organization’s network.

The CorelDRAW Graphics Suite 2019 Deployment Guide provides more information about network installations. To purchase a volume license of the software, please contact Corel Support Services.

How do I change the language of the user interface and Help?

You can change the language of the user interface and Help only if you have purchased and installed a multilingual version of the suite.
