Portable Plasma Torch Height Controller Manual (F1620)
small, gun will not be uplifted.
12 Torch is easy to
Arc voltage setting Increasing the arc voltage setting point
collide steel plate is too small
during torch work
13 During auto height The THC
Reducing the sensitivity coefficient P07 slightly
control work, torch sensitivity is too
is easy to vibrate
high
14 When touch work in The THC
1. Increasing sensitivity coefficient P07
the relatively steep sensitivity is too slightly
slope, arc voltage small, or lifting
2. Changing lifting motor which have faster
follow speed is too motor speed is too speed
small
small
15 Arc breaking is
After plasm arc CNC can receive arc feedback signal which
happened during
breaking have
make by plasma
torch work, CNC do happened, arc
not make torch stop voltage do not
work right away
decline right away.
After THC receive
this signal, it think
arc start is working
normally, and do
not send arc
breaking signal
16 The green nixie tube Data storage go User should post it back our factory, we can
display LIC after wrong
repair it.
starting up
17 When program is
USB read-write
1. Please upgrade again after powering off .
upgrading, after
speed does not
2. Please upgrade again after replacing the
pressing the enter match
USB flash disk.
key, the machine do
not work and do not
accomplish the
upgrade.
37
