Portable Plasma Torch Height Controller Manual (F1620)
THC（F1620 type）
TO CNC
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
1.10
AUTO
UP
DOWN
IHS_ARCON
DIR_ARCON
TRANSFER1
TRANSFER2
COM
COLLISION
PE
F2000 series CNC
output
ports
input
ports
1
14
2
15
3
16
4
17
5
18
6
25
13
connected
inside in
CNC
1
14
2
16
4
18
6
25
13
Figure 3.4 the connection diagram of connecting with fangling CNC
3.2.2 Power supply, motor and motor limit port
THC use dc 24V to provide voltage, the biggest power supply scope is 22V-34V, the power
of dc 24V is depended on the motor power, the power of dc supply should be greater value-added
between motor power and 5W.
Power supply port, motor and motor limit port use the same set of plug. The plug wiring
defined as follows:
22
