 Y – rotate angle, can be set from -360° to 360°.

 I – image of X axis, make image along X axis, 1 expresses that there is image, 0

expresses that there is no image.

 J –image of Y axis, make image along Y axis, 1 expresses that there is image, 0

expresses that there is no image.

Note:

A code can have G99, also cannot. If there is G99, the parameter X, Y, I, J after code

should not be ignored. Mirror image and rotation will take the origin (0, 0) of Descartes

coordinate as reference point.

10. Program notice items

 The program must contain the instruction of G92 (reference point setting) and

M02(end of program).

 G41/G42 must match with G40 to be used. If G41/G42 is ignored, the default kerf

compensation is zero; if G40 is ignored, kerf compensation is available.

 If G20 / G21 is ignored, the system will execute G21 (metric unit).

 If G90 / G91 is ignored, the system will execute G91 (relative coordinate).

 M07 and M08 can’t be neglected.

 When there is one parameter in the code of G00、G01、G02、G03 is ignored, if this

parameter is absolute coordinate, the system will set it G code coordinate value of last

row; If it’s relative coordinate, the system will set it 0.

 G00、G01、G02、G03 can be simplified: G0、G1、G2、G3.

 If there is contiguous G00 (or G01、G02、G03) around, the following G00 (or G01、

G02、G03) can be ignored.

10.4 M Code Explanation

M07

M08

M00

M02/M30

Table 10.3 Common M code

No parameter

Cutting device on

Cutting device off

End of instruction

End of program

 M07 Cutting device on

Please refer to Appendix 2 I/O Timing Sequence Figure of F2000 Series Numerical

Control System.

 M08 Cutting device off

Please refer to Appendix 2 I/O Timing Sequence Figure of F2000 Series Numerical
