Chapter 9 Graph Management
Lead In
Lead Out
Size 1
Size 2
10.00
10.00
100.00
100.00
1
F1 Inside F2 Outside
Lead out
Lead in
F8 OK
Fig 9.2 Chip size interface
You can press【 ↑】、【↓】、【←】、【→】to modify sizes, after modification , press
【F8】to confirmed.
Press any key to return to graphics processing interface as shown in Fig3.3.
9.2 Film/Hole Size
In Fig 9.2 interface, you can press【F2】to choose hole size, shown as Fig 9.3:
