8.7.5 Motor
Chapter 8 Diagnosis Function
Horizontal direction CW
▌
Vertical direction CCW
XY exchange
No
Press Enter to change.
F1 Input F2 Output F3 Axes F4 Motor F5 Option
F8 Save
Fig 8.11 Motor direction
Press up or down key, move the cursor ▌to the axes of which needs to change motor
rotation direction, then press 【Enter】, the motor direction can switch between positive
and reversal.
XY exchange: if this function is “YES”, output pulse of X axis and Y axis exchange
each other, in other words, horizontal axis and vertical axis exchange each other.
