Chapter 7 Parameter Setting
Marker Ignition Time
0.00
s
Marker Preheat Time
0.00
s
Mix powder Open Time
0.00
s
Mix powder Close Time
0.00
s
Marker Up Time
0.00
s
Marker Down Time
0.00
s
Marker Horizontal Offset
0.000
mm
Marker Vertical Offset
0.000
mm
F1 Common F2 Flame F3 Plasma F4 Powder F5 System F6 Import F7 Export F8 Save
Fig 7.5 powder parameters
Marker Ignition Time：Input ≥0 arbitrary value, unit: s.
Marker Preheat Time：Input ≥0 arbitrary value, unit: s.
Mix powder Open/Close Time：Delay time of scatter powder mouth relative to spurt
powder mouth open/close, input ≥0 arbitrary value, unit: s.
Marker Up Time：The time of powder torch going up. Unit: s.
Marker Down Time：The time of powder torch going down. Unit: s.
Marker Horizontal Offset：Horizontal offset of powder gun relative to cutting torch.
Unit: mm.
Marker Vertical Offset：Vertical offset of powder gun relative to cutting torch. Unit:
mm.
7.5 System Parameters
The system parameters, as shown in Fig 7.6, are related with the precision of driver
shaft of the cutting machine, coordinate axis, increase/decrease of rate and little arc
processing limited parameter.
57
