Chapter 7 Parameter Setting

In the main interface, you can get the parameter interface by pressing key【F4】

(Setups). The parameter function interface is showed in Fig 7.1

Max cutting speed

Manual move speed

G00 move Speed

Demo/back speed

Dust speed

Kerf value

Corner speed(1-100)

Cutting type

Demo Run Speed

1000.000

3000.000

1000.000

2000.000

1000.000

1.000

100.000

Flame

1000.000

mmpm

% mmpm

<->

mmpm

F1 Common F2 Flame F3 Plasma F4 Powder F5 System F6 Import F7 Export F8 Save

Fig7.1 Parameter Interface

You can set five kinds of parameter in the parameter interface:

1) Common parameters: cutting speed, manual move speed, G00 move speed, the size of

kerf gap, corner speed, cutting type, edge cut enable, hold preheat.

2) Flame parameters: all the parameters used in oxygen gas cutting

3) Plasma parameters: all the parameters used in plasma cutting

4) Powder parameters: ignition, perforation cycle parameters, dry dusting offset

5) System parameters: you can set system pulses, maximum speed limit, motor

parameters and soft limit parameters.

7.1 Common Parameters

It is the favorite’s parameters in Fig7.1.
