Appendix 3 Interpretation of Wiring Connection between F2000 Series and Common THC
Input definition
Port
Position detect
05
Output definition
Port
Lock THC
18
Type
●
Type
●
The method of definition:
F2100B, F2200B, F2300 A/B, F2500 A/B, F2600:
F5 (Diagnose), F8 (System Def), F3 (define), input password: 1396.
131
