Chapter 11 Port Explanation
11.4.3 Position Interface (PS) Instruction
Position interface (PS) is also in the 7 pins interface like arc import. Input pins are
+24V(OUT), SIGNAL,COM. +24V(OUT) links with the positive pole of location approach
switch, SIGNAL links with the signal of NPN approach switch, COM links with the
negative pole of location approach switch.
Interpret：Approach switch is NPN type with DC24V.
Table 11.6 Position Interface Signal Definition of Arc THC Module
7 Cores Interface Pin Number Signal Name
Comment
1
COM
Negative pole of approach switch
2
SIGNAL
NPN approach switch signal
3
+24V(OUT)
Positive pole of approach switch
11.4.4 Arcing interface (ARC_START) instruction
Arcing interface (ARC_START) is also in the 7 pins interface like arc import. Output
pins are ARC_START1、ARC_START2 linking with plasma power arcing port.
Table 11.7 Arcing port Signal Definition of Arc THC Module
7 Cores Interface Pin Signal Name
Comment
6
ARC_START1 plasma power arcing port
7
ARC_START2 plasma power arcing port
