Chapter 11 Port Explanation
11.3.1.3 Connection Methods of Servo Driver of Panasonic Company
XDIR+ 1
XDIR-
9
XCP+ 2
XCP-
10
YDIR+ 3
YDIR-
11
YCP+
YCP-
4
12
5
13
6
+5V
5VG
5VG
14
7
15
8
5 SING1
6 SIGN2
3 PULS1
4 PULS2
Power
input
Panasonic
A5/A4
5 SING1
6 SIGN2
3 PULS1
4 PULS2
Power
input
Panasonic
A5/A4
Figure 11.11 Connection methods of Servo driver of Panasonic Company
102
    "
