Plasma LGK-400IGBT （Compressor refrigeration 1.5-2p）
Model
LGK-400IGBT
Cutting ability (Stainless steel) High quality cutting 40mm (Cutting thickness)
Perforation cutting 40mm (Cutting thickness)
Maximum cutting
45mm(Cutting thickness)
Cutting ability (carbon steel)
High quality cutting 45mm (Cutting thickness)
Cutting current
Load persistence rate
Perforation cutting
Maximum cutting
45mm (Cutting thickness)
50mm(Cutting thickness)
30A~400A
100%（ambient temperature 40º）
Cutting parameters(Stainless steel) actual measurement
Cutting parameters(carbon steel)) actual measurement
technical parameter
Product certification
Plasma gas
Power supply
Rated power
No-load voltage
Host weight
Shape size
Mounting dimensions of host base
Water chiller 1.5P (compressor refrigeration, constant
temperature control)
Ground: ≥ 50 ² Power cord: ≥ 35 ²
Packing size (wooden case) Length * Width * Height
35mm（Cutting thickness）,
1000mm/min（Cutting speed）
35mm（Cutting thickness）,
1200mm/min（Cutting speed）
3~380V，
95 KVA
380V
129 kg
Long*Wide*High 890*430*875mm
3C CE
Air (no oil, no water) is recommended to
connect as shown on the right
As shown on the right
Fine cutting torch 400A diameter 50mm
7.5 m cable
Optional stop valve
1000*470*1100mm
    "
