Fig. 5-9 Lean Tilt Setting Box
Transformation
Lean
X 0 X 0 degree
Y 0 Y 0 degree
Apply to Copy Object
Apply
Angle: The angle the object leans.
Tilt: Represents the slope angle of the currently selected object.
: Select a datum mark of an object.
Apply
: Let the modification of the current object active.
Apply to copy object : Move selection to a new location
: This item is used to copy the currently selected object
and lean it into a new place.
129 / 217
    "
