Input Port Marking
Marking by Graphs
Equiangular Marking
360 360 Degree Rotation Marking
Times per Week
Return to Start Position after Marking
Number of Completions
Total Time
Red Light Indicator
Marking
Parameters
Exit
…… Marking Not Started......
，：
In the dialog box, the data items are described as follows:
Total Number: The total counts that the marking command should be
executed. If checking the “Continuous”, the marking number will not be limited
by the total number;
Rotary Axis：Choose which axis to use；
Continuous Mark: If it is checked, it will not be controlled by the total number,
and it will perform continuous marking for graphs or text contents displayed in
the workspace.
Mark Selected: If it is checked, only those selected graphs will be marked;
otherwise, all the graphs will be marked;
Input trig port marking: Specify an input port and the marking can be
triggered through the IO port.
Overall Marking of Graph: Mark the individual graph or text as a whole at a
time, and after marking an individual graph, rotate for an angle.
148 / 217
