LMC2014 users' manual_Fiber
1.2 main feature
Standard DB25 connector, can be wire to IPG laser directly.
Galvo control signal is digital, which can be connect to most scanhead directly.
on-the-fly marking feature. A encoder can be used to surveillance the pipeline speed
real-timely.
Multiple boards on 1 computer: One computer can control up to 8 control board to mark
different pattern simultaneously
Extension axis(step motor or sever motor): two set of direction/pulse signal can be used to
control 2 step(server) motors.
16 general input signals(TTL campatible): In0-In13, XORG0(IN14), YORG0(IN15).
8 general output signals(TTL campatible): Out0-7 coming out of Con5. Out0 - 3 are TTL
outputs. Out4-7 can be configured as OC outputs or TTL outputs.
LaserErr signal: this signal will be activated when there is an error occurs in the laser, OC
output.
Remark function: this function is used to remark what ever is in the memory of the board,
especially convenient for high speed marking of a same pattern.
Compatible with USB2.0 specifications.
1.3 Version illustration
In 2014 we update the board, on left top corner you will see the ' REV: 20141022', used to
control D type laser, also can control B type laser. And also support YLPM type of laser.
REV
LaserType BType
DType
Comment
REV20070716-2
REV20080425-3
REV20100511
REV20101221
support
support
support
support
Not support
support
support
support
Old
USBLMC
2010 new
2010 new
2 electrical wiring
2.1 pin definition
2.1.1 power supply
The control board need a 5V DC power supply. We recommend a 5V/3A DC supply. The Vcc
and Gnd pin are 4/5 and 12/13 of CON4 respectively. You may find in other connectors some
Vcc/Gnd pins, but we strongly suggest you use the ones in CON4.
