216 CON5 216 CON5 DB25 digital IO pin name 1 2 (Page 12 / 19) LMC2014 Fiber-Laser-Control-Board

LMC2014 users' manual_Fiber

2.1.6 CON5：2.1.6 CON5：DB25 digital IO

name

1，2，4,

5，14，15， Out0——7

16，17

COM

Fig 2- 5 CON5 pin definition

function

General Output Out 0 — Out 7, using GND as reference

ground. They are all TTL output by default. Out 4-Out 7

can be configured to perform as a OC out put by jumper

JP8-11.

OC output, connect it to plus end of the pull power(for

example 24V), in case of the output circuit will be

wracked by inductiveload(for example: inductive relay)
