LMC2014 users' manual_Fiber

4，5 Vin

12，13 Gnd

6，14 XDIR+/XDIR-

7，15 XPUL+/XPUL-

ReMark

can be either a differential output or a TTL output(common

anode).For common anode, use VCC and YPUL+ signals, and

VCC is anode signal.

Input pin for 5V power supply.

Reference ground of 5V power supply

Direction signal of extension axis Y (step motor or sever

motor). It can be either a differential output or a TTL

output(common anode).For common anode, use VCC and

XDIR+ signals, and VCC is anode signal.

Pulse signal of extension axis Y (step motor or sever motor). It

can be either a differential output or a TTL output(common

anode).For common anode, use VCC and XPUL+ signals, and

VCC is anode signal.

Repeat marking signal. Use GND as a reference ground, to use

this signal just connect a switch between this pin and GND.

When it is activated the control will mark the content in the

cache.
