User Manual of Machine Vision Camera SDK Demo (LabVIEW)
Chapter 3TwoCameraSamples
TwoCameraSamples is a sample program of LabVIEW two cameras, which can realize the function of two
cameras control.
3.1 Interface Overview
The TwoCameraSamples for machine vision camera can realize the function of device refresh,
initialization, and image acquisition.
3.2 Operation Procedure
Steps:
1. Click Refrsh Devices to search the online device.
The online devices will display in the drop-down list of the upper left corner field.
Note: If the user ID is not empty, the devices will be displayed as “device name”; when the device name is
empty, the devices will be displayed as “device model” + ”Serial No.”.
2. Click to select a device in the drop-down list.
3. Click Open Device button in the Initialization field to active the Acquisition field.
4. Select image acquisition mode as Continuous or Trigger Mode.
Notes:
The default image acquisition mode is Continuous.
